Lovato  |  SKU: LMS25025T

11LMS25025T

$0.00
Shipping calculated at checkout.

Lovato 11LMS25 025T manual motor protector with an adjustable range of 0.16-0.25 AMPS, DIN rail mounting and Start/Stop pushbutton operation. Class 10 Tripping Characteristic and Single Phase Sensitive.



Catalog Page / Specifications

Need a slightly lower AMP range? Click here to see the LMS25016T.
Need a slightly higher AMP range? Click here to see the LMS2504T.

Obsolete - Please see link above for replacement

Operational characteristics: – Rated insulation voltage Ui: 690V – Rated impulse withstand voltage: 6kV – Rated frequency: 50/60Hz – Maximum rated current: 25A – 13 adjustment ranges 0.1 to 25A – Power dissipation: 2-15W – Magnetic tripping: 12In max – Thermal tripping class: 10 – Phase failure sensitive – Mechanical life: 100,000 cycles – Electrical life 25A (AC3): 100,000 cycles – Mounting on 35mm DIN rail (IEC/EN 60715) or screw fixing – Mounting position: Any – Utilisation category: A – Degree of protection: IP20.

Certifications and compliance Certifications obtained: GOST; cULus. Compliant with standards: IEC/EN 60947-1, IEC/EN 60947-2, IEC/EN 60947-4-1.

Wide adjustment range from 0.1 to 100A Breaking capacity Icu 50kA (400V) up to 100A Suitable for isolation Comprehensive line of accessories Front mount contacts Automatic trip indicators High reliability and accuracy of tripping.

lovato logo

Delivery and Shipping

We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.

Lovato's line of LMS manual motor starters are available in AMP ranges from 0.10 up to 25 AMPS in 13 different sizes. With an easy Start/Stop pushbutton manual operation, these LMS motor protectors are suitable for controlling small motor and machines. Additional undervoltage trips and auxiliary contacts that snap on are just some of the many accessories you can add to increase the units level of protection and operating complexity.

Click here for a catalog page on the LMS25 manual motor protector
