Other  |  SKU: ZB65-65

ZB65-65

$102.01 $305.78
Shipping calculated at checkout.
Eaton/Moeller ZB65-65 thermal overload relay that is adjustable from 50 to 65 AMPS, has 1 normally open and 1 normally closed auxiliary contact and mounts to the load side any DILM40 through DILM65 3 pole contactor. The ZB65 series of overloads has phase loss protection along with class 10 tripping, which will cut power to the contactor in 10 seconds or less in an over current condition. For a higher AMP range than the ZB65-65, the ZB65-75 offers an adjustable range from 65 to 75 AMPS and mounts to the same frame size contactors.

Catalog Page / Specifications

Stock - Can ship today if ordered prior to 4 p.m. EST

Class 10 overload; trip response from 2 to 10 seconds Ambient compensated, bimetallic overload tripping mechanism Phase failure sensitive to IEC/EN 60947 Manual / Automatic reset button Built-in NO and NC auxiliary contacts Direct mount to DILM40, DILM50 and DILM65 contactors Can be mounted separately only standard 35mm DIN rail with additional of ZB65-XEZ bracket

eaton logo

Delivery and Shipping

We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.

Modern motors are built with less metal, which means they dissipate less heat. This calls for the modern protection offered by IEC-style Class 10 overload relays...they trip in 10 seconds under locked rotor conditions. Most motor manufacturers today recommend this type of “close” protection. All Moeller series ZB65 overload relays come with a host of standard features including phase-failure sensitivity, temperature compensation, test / reset buttons and a tripfree release. The auxiliary contacts of the relay disconnect the motor contactor and signal a fault. Moeller series relays can also be used for protecting EExe hazardous location motors.

Click here for a catalog page on the ZB65 overload relay
