DILM25-01 (RDC24)
Moeller Electric (formerly Klockner Moeller) has been known throughout the industry as having the most reliable, longest lasting contactors and motor controls. In fact, many of their contactors last 20 years, saving you the time and cost of frequent replacement. The DILM line of IEC and UL rated 3 pole contactors is no different. They also have a wide range of accessories, from DILM32 and DILM150 front and side mounted auxiliaries, to the ZB line of thermal magnetic overload relays. All accessories are tool-less installation and offer numerous possibilities for contact arrangement and motor protection.
| MAXIMUM HORSEPOWER | MAXIMUM CURRENT | # OF POLES | AUXILIARY CONTACTS | CATALOG # | COIL VOLTAGE | ||||||||
| Single Phase | Three Phase | Inductive AC-1 (A) | Resistive AC-3 (A) | N.O. | N.C. | N.O. | N.C. | ||||||
| 115v HP | 230v HP | 200v HP | 230v HP | 460v HP | 575v HP | ||||||||
| 2 | 5 | 7.5 | 10 | 15 | 20 | 25 | 40 | 3 | 0 | 0 | 1 | DILM25-01 | 24VDC |
