DILM12-10 (220V50Hz/240V60Hz)
Need help finding the coil voltage? Click here to see a picture to help determine the location of the coil voltage for this contactor.
DILM12-10 240 volt Datasheet
Ships same day up until 4 p.m. EST
1-2 days for item to ship for standard delivery
Can be shipped direct from manufacturer for next day delivery if out of stock at IMC-DIRECT warehouse
DILM12-10 (220V50Hz/240V60Hz) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.
DILM12-10 (220V50Hz/240V60Hz)
Moeller Electric (formerly Klockner Moeller) has been known throughout the industry as having the most reliable, longest lasting contactors and motor controls. In fact, many of their contactors last 20 years, saving you the time and cost of frequent replacement. The DILM line of IEC and UL rated 3 pole contactors is no different. They also have a wide range of accessories, from DILM32 and DILM150 front and side mounted auxiliaries, to the ZB line of thermal magnetic overload relays. All accessories are tool-less installation and offer numerous possibilities for contact arrangement and motor protection.
| MAXIMUM HORSEPOWER | MAXIMUM CURRENT | # OF POLES | AUXILIARY CONTACTS | CATALOG # | COIL VOLTAGE | ||||||||
| Single Phase | Three Phase | Inductive AC-1 (A) | Resistive AC-3 (A) | N.O. | N.C. | N.O. | N.C. | ||||||
| 115v HP | 230v HP | 200v HP | 230v HP | 460v HP | 575v HP | ||||||||
| 1 | 2 | 3 | 3 | 10 | 10 | 12 | 20 | 3 | 0 | 1 | 0 | DILM12-10 | 220V50Hz/240V60Hz |
