DILEM-01-G (24VDC)
DILEM-01-G 24 volt DC Datasheet
Country of Origin : Romania
Schedule B / H.T.S. : 8536.49.0065
Ships same day up until 4 p.m. EST
1-2 days for item to ship for standard delivery
Can be shipped direct from manufacturer for next day delivery if out of stock at IMC-DIRECT warehouse
DILEM-01-G (24VDC) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.
DILEM-01-G (24VDC)
Moeller offers a miniature contactor, the DILEM. Designed for small loads, it is available in units up to 20A, and provides reliable performance for motors up to 5HP (@575V). AC and DC units are available. This Moeller miniature contactor features a large ambienttemperature range, and its low power consumption permits direct actuation from a PLC. The DC version
of the DILEM also includes an integrated suppressor to protect from voltage peaks that may occur when the coil is disconnected. Top-mount auxiliary contacts are available in both 2- and 4-pole configurations. Moeller’s DILM and DIL EM contactors carry UL, CSA, IEC/EN 60947 and VDE 0660 approvals. They are manufactured to ISO 9001 quality standards.
| MAXIMUM HORSEPOWER | MAXIMUM CURRENT | # OF POLES | AUXILIARY CONTACTS | CATALOG # | COIL VOLTAGE | ||||||||
| Single Phase | Three Phase | Inductive AC-1 (A) | Resistive AC-3 (A) | N.O. | N.C. | N.O. | N.C. | ||||||
| 115v HP | 230v HP | 200v HP | 230v HP | 460v HP | 575v HP | ||||||||
| 0.5 | 1.5 | 2 | 3 | 5 | 5 | 15 | 15 | 3 | 0 | 0 | 1 | DILEM-01-G | 24vDC |
