Other | SKU:
DILA-22-(24vDC)
66% off
DILA-22 (24vDC)
$55.37
$162.00
Unit price
/
Unavailable
Shipping calculated at checkout.
The Eaton/Moeller DILA-22 (24vDC) four pole control relay comes with 2 normally open and 2 normally closed poles and a 24 volt DC rated coil. This industrial control relay is rated for 10 AMPS, has screw terminals and extra DILA-XHI auxiliaries can be added for up to 4 more additional contacts. For a different pole configuration than the DILA-22 24 volt DC, Eaton offers the DILA-31, which has 3 normally open and 1 normally closed poles, and the DILA-40, which has 4 normally open poles.
DILA-22 Datasheet
DILA-22 Datasheet
Stock - Can ship today if ordered prior to 4 p.m. EST
DILA-22 (24vDC) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.
DILA-22 (24vDC)
$55.37
$162.00
Unit price
/
Unavailable
Base DILA-22 control relays have four-poles rated to 10 amps, (UL/CSA general purpose). Two and four-pole auxiliary contact blocks may be added to increase the relay’s capacity to a maximum of eight poles. Various NO and NC configurations are available, including late break and early make. Auxiliary contacts are also rated to 10 amps. A comprehensive range of accessories from suppressors and voltage indicators to amplifiers and timing modules make DIL A relays a great choice for applications demanding maximum flexibility.
