Siemens  |  SKU: 3RV1011-0DA10

3RV10110DA10

$0.00
Shipping calculated at checkout.
Siemens 3RV1011-0DA10 Manual Motor Starter/Overload Protector that is adjustable from 0.22-0.32A, mounts on the DIN rail and has a Class 10 tripping characteristic - comes with screw terminals, reset button and optional front and side mounted auxiliaries can be added.



3RV1011-0AA10 Datasheet

Need a slightly lower AMP range? Click here to see the 3RV1011-0CA10.
Need a slightly higher AMP range? Click here to see the 3RV1011-0EA10.

Obsolete - Please see link above for replacement

ON/OFF rocker mechanism with lockout. Adjustment dial for setting to motor FLA. Class 10 overload trip characteristics. Short circuit trip at 12 times the maximum setting of the FLA adjustment dial. Short circuit current rating: Ambient compensated up to 140° F (applies to side by side mounting). Phase loss sensitivity. Test trip function.

siemens logo

Delivery and Shipping

We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.

The 3RV1011 MSP’s, can be used as components in Group Installation per NEC 430-53(C) to turn motors on and off. Each device has built-in heater elements that provide overload protection and magnetic trip elements to protect the motor. When the 3RV1011-0DA10 is used as a component in Group Installation, multiple MSP’s can be installed below one circuit breaker to protect its own motor. A contactor can be mounted to the MSP to provide a remotely operated starter.

Click here for a catalog page of this 3RV1 Manual Motor Protector
