GE Industrial  |  SKU: RT1M
Obsolete

RT1M

$0.00
Shipping calculated at checkout.
GE RT1M overload relay adjustable from 5.5-8.5 AMPS - Manual or Automatic Reset - Class 10 tripping characteristic - 2 base mounted auxiliary contacts and phase loss protection - Mounts directly to any CL00, CL01, CL02, CL25, CL04 or CL45 3 pole contactor

RT1M Datasheet

Need a slightly lower AMP range? Click here to see the RT1L
Need a slightly higher AMP range? Click here to see the RT1N

Obsolete - Please call 877.334.7893 for replacement

ge logo

Delivery and Shipping

We ship the same day on all in stock orders that are placed prior to 4 p.m. EST, Monday through Friday. We offer Flat Rate shipping ($9.00 for UPS Ground) and expedited shipping can be selected at checkout.

GE offers a line of RT1 overload relays that directly mount to the GE CL line of contactors from 5-25 H.P. (CL00-CL45). Each overload relay has Class 10 tripping characteristics, is 3-pole with phase loss protection, Manual or Automatic Reset and two independent double break contacts. These RT1 overloads directly mount to the load side of any GE contactor and have an adjustable dial with ranges from 0.16 AMPS up to 32 AMPS, depending on the motors Full Load AMPS (FLA).

Click here for a catalog page of this GE Overload
